DA43
TV Signal Distribution Amplifier
DA43
TV Signal Distribution Amplifier
Discontinued
New Product: DA44
3
Year
Warranty
TV Signal Distribution Amplifier with 43dB Gain, Single Input, Frequency Range of 40-860 MHz & can be either locally or remotely powered
Kingray’s DA and DW series distribution amplifiers have been designed for today’s digital television signals. The technology used is hybrid bipolar and GaAs, which allows for a greater output capacity, whilst having a lower noise figure. The amplifiers contain mid-stage gain controls, a number of flexible powering options and are built in a fully shielded die-cast housing. The DA43 distribution amplifier has a single input.
Australian Made
Terrestrial / Free-To-Air TV Amplifier
VHF Distribution Amplifier
UHF Distribution Amplifier
Foxtel Approved (F31091)
Product Details
Key Features
- Frequency Range 40-860 MHz
- 43dB Maximum Gain
- 20dB Mid Stage Gain Control
- Single Input
- Local or Remote Powering Options
- Adjustable Slope Control of 5-15dB
- -30dB Test Point
- High Output Figure of 118dB IMR3 (DIN45004B)
- Ability to send power via the RF Input
- Connectors: F-Type
- Power Consumption: 300mA
- Operating Voltage: 18V DC
- Operating Temperature: -10ºC to 50ºC
- Suitable Power Supply: PSK18S or PSK18F
In the box
- DA43
- Instruction Manual
- Mounting Screws
